California Air Tools 20015HP Ultra Quiet 1.5 HP Oil-Free High-Pressure 20-Gallon Air Compressor

Product Description

The California Air Tools 20015HP is a 1.5 HP high-pressure, oil-free, two-stage air compressor designed for applications requiring higher operating pressure and strong airflow. It features a 20-gallon steel air tank and delivers up to 175 PSI, with 4.00 CFM at 40 PSI and 3.80 CFM at 90 PSI.

The motor operates at 1,750 RPM and is designed to reduce noise and wear while supporting longer operating periods. Its oil-free dual-piston pump is engineered for a service life of more than 3,000 hours before wear.

The 20-gallon steel tank is mounted on a wheel kit for easier movement around a shop, garage, or jobsite. With an operating noise level of 70 dB, the 20015HP is designed to provide high-pressure compressed air with lower noise than many conventional compressors.

Key Features

• 1.5 HP rated/running motor
• High-pressure 175 PSI operation
• Oil-free two-stage dual-piston pump
• 20-gallon steel air tank
• 4.00 CFM at 40 PSI
• 3.80 CFM at 90 PSI
• 70 dB operating noise
• 1,750 RPM motor speed
• 145–175 PSI operating pressure
• Two pressure control gauges
• Two female industrial push-to-connect quick connectors
• Condor pressure switch
• Thermal overload protection
• 110V / 60 Hz operation
• 12-amp draw
• 70/30 duty cycle
• Wheel kit for portability
• Two air filters
• Non-ASME air tank
• 1-year limited warranty

Specifications

What's Included

• California Air Tools 20015HP air compressor
• 20-gallon steel air tank
• Wheel kit
• Two air filters

Applications

The 20015HP is suitable for applications requiring higher compressed-air pressure, including:

• Professional workshops
• Garages
• Automotive applications
• Pneumatic tools
• High-pressure air applications
• Shop and jobsite applications
• Applications requiring greater pressure than a standard 120–135 PSI compressor

The 20-gallon tank and 175 PSI maximum pressure make this model particularly suited to applications where higher stored air pressure is required.

Maintenance

The 20015HP uses an oil-free pump, eliminating the need for routine pump oil changes.

The compressor comes with two air filters. The manufacturer specifies a 1-year limited warranty and recommends following the owner's manual for operating and maintenance procedures.

The compressor should be operated within its specified 70/30 duty cycle and pressure limits to support proper performance and service life.
