California Air Tools 91328 Strainer Filter Ball Valve – 250 PSI

California Air Tools 91328 Strainer Filter Ball Valve – 250 PSI

The California Air Tools 91328 Strainer Filter Ball Valve is designed for compressed-air tank drainage systems. It combines a stainless steel filter screen with a ball valve to help prevent larger solid impurities from blocking downstream drain components.

The valve can be connected to an air tank drain system, including compatible timer-controlled automatic drain valves or zero-loss drains. Its shutoff function allows the air flow to be temporarily closed when the drainage system requires maintenance.

Key Features

• Combined strainer filter and ball valve design
• Stainless steel filter screen helps capture larger solid impurities
• Brass valve body
• Aluminum alloy ball valve handle
• Maximum working pressure of 250 PSI
• Dual inlet connections: 1/4-inch NPT female or 1/2-inch NPT male
• 1/4-inch NPT male outlet connection
• Designed for compressed-air tank drainage and maintenance applications

Specifications

Application

This valve is intended for compatible compressed-air tank drainage systems. Confirm the inlet connection, outlet connection, and pressure rating required by your installation before ordering.

Maintenance Note

The ball valve can temporarily shut off flow to support drain-system maintenance. Depressurize the system and follow the compressor manufacturer's safety instructions before servicing any drain components.
